• Large 3840Wh capacity.
• 51.2V / 75Ah electrical configuration.
• LFP (LiFePO4) cells.
• More than 3500 cycles while maintaining over 80% capacity.
• Two MJ32 ports for daisy-chain connection.
• Expandable system for increasing total storage capacity.
• LED indicator for checking the battery level.
• Communication with the compatible PECRON power station for charging and discharging management.
• Suitable for home backup, camping, RVs and off-grid systems.

PECRON EP3800-48V provides a capacity of 3840Wh (51.2V / 75Ah), allowing you to expand the energy reserves of a compatible PECRON power station. The additional capacity is useful when the system needs to support longer periods of use without recharging.

• Model: PECRON EP3800-48V.
• Capacity: 3840Wh.
• Voltage: 51.2V.
• Rated capacity: 75Ah.
• Cell technology: LFP (LiFePO4).
• Lifespan: over 80% capacity after 3500 cycles.

The battery uses LFP (LiFePO4 – Lithium Iron Phosphate) cells, a technology designed for a long service life and stable energy delivery. According to the provided specifications, the battery retains more than 80% of its capacity after approximately 3500 cycles.

PECRON EP3800-48V is equipped with two MJ32 ports, designed for connection to compatible devices and for creating an expandable energy storage system.

• Additional battery ports: 2 × MJ32.
• Support for daisy-chain connection.
• Compatible with devices equipped with an MJ32 daisy-chain port.
• Allows system expansion by connecting compatible batteries.

The integrated communication ports allow the expansion battery to synchronize with a compatible PECRON power station. The system can therefore coordinate charging and discharging processes within the connected energy configuration.

The integrated LED indicator allows you to quickly check the available battery level, providing a simple way to monitor the remaining capacity.

PECRON EP3800-48V is designed to expand compatible PECRON systems and can be used with devices equipped with an MJ32 daisy-chain port.

• PECRON E1500LFP.
• PECRON E3600LFP.
• PECRON E1000LFP.
• PECRON devices compatible with an MJ32 daisy-chain port.

• Portable power station expansion: increases the energy capacity and runtime of a compatible PECRON system.
• Home backup: adds extra capacity for power outage situations.
• Camping and outdoor activities: suitable for extended periods of off-grid use.
• RV and Vanlife: allows you to expand energy reserves for equipment used while traveling.
• Off-grid systems: an additional storage solution for cabins and remote locations.

• Discharge / power supply ambient temperature: -20°C to +45°C.
• Charging ambient temperature: 0°C to +45°C.
• Storage temperature: -20°C to +45°C.
• Optimal storage range: +20°C to +30°C.
• Maximum operating altitude: 3000 m.

• 3840Wh energy capacity.
• 51.2V / 75Ah.
• LiFePO4 technology.
• 3500+ cycles while maintaining over 80% capacity.
• 2 × MJ32 ports.
• Daisy-chain connection.
• Smart communication with the compatible system.
• LED battery level indicator.
• Maximum operating altitude of 3000 m.

• Significantly increases the storage capacity of a compatible PECRON system.
• Large 3.84kWh capacity in a single expansion battery.
• Long-life LiFePO4 cells.
• Expandable through daisy-chain connection.
• Simple monitoring via the LED indicator.
• Suitable for use at home, on the go or in off-grid systems.

• Dimensions: 441 × 312 × 223 mm.
• Dimensions in inches: 17.3 × 12.2 × 8.8 inch.
• Net weight: approximately 30.3 kg.
• Weight in lbs: approximately 66.8 lbs.

• 1 × PECRON EP3800-48V Expansion Battery.
• 12 × Screws.
• 1 × Flathead Screwdriver.
• 1 × Accessory Case / Pouch.
• 1 × User Manual.
